Deye SUN-MPPT-L01-EU-AM8 200kWp 8-Tracker MPPT Module

1,380 ~1,450 €/pcVAT excluded

Inquiry Us Add Product
PREV: No previous product NEXT: No next product
  • Product Description

Uni Z International B.V.+31610999937

Uni Z International B.V.[email protected]

Turn complex commercial PV fields into stable, harvest-ready DC power. Eight independent trackers reduce the impact of uneven orientation, partial shading and string mismatch, while the broad 180-750V MPPT range gives designers more freedom across rooftop and ground-mount layouts. With 200kWp input capacity, >99.9% tracking efficiency and an IP65 enclosure, the SUN-MPPT-L01-EU-AM8 is purpose-built to pair with Deye C&I PCS platforms for modular solar-plus-storage systems that prioritize yield, serviceability and future expansion.

PV input up to 200 kWp;
max PV voltage 800 V;
start-up voltage 200 V
MPPT range 180-750 V;
full-load range 450-750 V;
rated PV input 600 V
Tracking 8 independent MPPT channels; 40 A operating / 60 A short-circuit per channel
Efficiency >99% max;
 MPPT tracking >99.9%
DC output 630-1000 V; max 200 A
Protection reverse-polarity, DC switch, Type II SPD; optional arc and anti-PID functions
Enclosure/cooling IP65; intelligent air cooling
Dimensions/weight 543 x 198 x 700 mm; 41.75 kg

MPPT Module SUN-MPPT-LO1-EU-AM8
PV String Input Data
Max.PV Input Power (kW) 200
Max. PV Input Voltage (V) 800
Start-up Voltage (V) 200
MPPT Voltage Range (V) 180-750
Full Load MPPT Voltage Range (V) 450-750
Rated PV Input Voltage (V) 600
Max. Operating PV Input Current (A) 40+40+40+40+40+40+40+40
Max. Input Short-Circuit Current (A) 60+60+60+60+60+60+60+60
No. of MPP Trackers 8
Efficiency
Max. Efficiency >99%
MPPT Efficiency >99.9%
Equipment Protection
DC input reverse protection YES
DC ARC protection Optional
Anti-PID(Potential Induced Degradation) Optional
DC Switch YES
Surge Protection Level TYPE II
General Data
Ingress Protection(IP) Rating IP65
Over Voltage Category OVC II
Cabinet Size[WXHXD] (mm) 543x198x700
Weight (kg) 41.75
Type Of Cooling Intelligent air cooling
Safety EMC/Standard IEC/EN 62109-1
DC Output Data
DC Output Voltage Range(V) 630－1000
Max. DC Output Current(A) 200
