Deye WS-MV5000-2 5MVA 1500V PCS with 10–35kV Step-Up Transformer

customizedVAT excluded

Inquiry Us Add Product
PREV: No previous product NEXT: No next product
  • Product Description

Uni Z International B.V.+31610999937

Uni Z International B.V.[email protected]

The Deye WS-MV5000-2 is not a battery container; it is the 5 MVA power-conversion and medium-voltage interface designed to turn utility-scale DC storage into grid-ready AC power. Four DC inputs accept up to 1500 V and 1404 A each, feeding two 2.5 MVA conversion channels for a combined 5 MVA rated output. The integrated 5,200 kVA oil-immersed transformer steps 690 V up to project-specific medium voltage in the 10–35 kV range, reducing the amount of external MV equipment an EPC must engineer around the PCS. Average conversion efficiency is specified at ≥98.3%, with THD below 3% at rated power and a full leading-to-lagging power-factor control range for grid-support operation. With IP65 protection on the PCS, -30°C to +60°C operation and communications via RS485, Ethernet and CAN, the WS-MV5000-2 is the grid-interface half of Deye's large-scale WS platform and should be listed separately from the 5.016 MWh battery container.

Function utility-scale PCS + step-up transformer system
Maximum DC voltage 1500 V
nominal-power DC operating range 1000–1500 V
Maximum DC current 1404 A × 4
DC inputs 4
Rated AC output 2500 kVA × 2 = 5 MVA
Maximum AC output 2500×1.1 kVA × 2 at 35°C
Rated AC voltage 690 V
AC range 621–759 V; 50/60 Hz
Maximum AC current 2300 A × 2; THD <3% at rated power
Power factor >0.99; adjustable 1 leading to 1 lagging
Average conversion efficiency ≥98.3%
Transformer oil-immersed, 5200 kVA; LV/MV 0.69 kV / 10–35 kV; vector group Dy11; ONAN/KNAN
Protection PCS IP65 / other compartments IP54
Operating temperature -30°C to +60°C, derating above +45°C; altitude up to 4000 m, derating above 2000 m
Communication RS485 / Ethernet / CAN; dimensions 6058×2438×2896 mm; weight ≤23 t
