Dyness Low Voltage ESS 10.24kwh PowerBOX G2

1450~1595 €/pcVAT excluded

Inquiry Us Add Product

PREV: Dyness Low Voltage ESS 5.12kwh BX51100 NEXT: Dyness Low Voltage ESS 14.336kwh PowerBrick

Product Description

Uni Z International B.V. +39 3444606026

Uni Z International B.V. [email protected]

Product Model: Powerbox G2
Battery Type: LiFePO4
Nominal Battery Energy: 10.24 kWh
Protection Level: IP65
Expansion: Up to 50 units in parallel
Cycle Life: Unlimited cycles/10 Years
Net Weight:96kg
Product Features:
Flexible Expansion(Up to 50 parallel units, 10.24-512kWh capacity, HUB-free.)
Automatic Self-HeatingCharges at -20℃, operate -20°C to 55°C (optional).
Ultra Safe(Smart Fire Suppression, 5-sec Response, Auto Pressure Relief.)
1C Rate(Max.output:10.24kW, Maximum continuous current: 200A, no black-out.)
Easy Installation(30% less volume, 15% less weight, save time and labor.)
Long-term Reliability(LFP cells, ultimate cycles, 10 years warranty.)

Model	Powerbox G2
Battery Type	LiFePO₄
Nominal Battery Energy	10.24kWh
Usable Energy	9.728kWh
Operating Voltage	44.8-57.6V
Nominal Voltage	51.2V
Nominal Capacity	200Ah
Nominal Charge or Discharge Power	5.12kW
Max Discharge Power	10.24kW
Recommended Charge & Discharge C Rate	0.5C
Max Discharge C Rate	1C
Recommended Charge/Discharge Current	100A
Max Discharge Current	200A
Peak Discharge Current	300A(2mins,25°C)
Recommended Depth of Discharge (DOD)	95%
Net Weight	96kg
Dimension[W/D/H] (mm)	710/165/640
Charging Temp. Range	0~55°C/-20~55°C (with heating function)
Discharging Temp. Range	-20~55°C
Communication	CAN/RS485
Cycle Life *	Unlimited cycles/10 Years
Protection Level	IP65
Expansion	Up to 50 units in parallel
Color	White
WIFI Module	Built-in WiFi module; APP OTA function
Battery low-temperature heating function	Optional
Active fire protection system	Built-in aerosol fire extinguisher
Certification & Safety Standard	UN38.3/CE-EMC/IEC62619/IEC62040/CE-RED/CEC/GOST-R
Compatible Inverters	SMA/Schneider/Victron energy/lngeteam/Solis/GoodWe/Growatt/Soplanet/Luxpower/DEYE etc.
