Zetara Magic – ZCube1290-MF

customizedVAT excluded

Inquiry Us Add Product

PREV: Zetara Magic – ZCube1720-HF NEXT: No next product

Product Description

Uni Z International B.V. +39 3444606026

Uni Z International B.V. [email protected]

The Magic-ZCube1290-MF is a power storage system specially designed for regional microgrids, including small CBDs, farms, islands, and outdoor photovoltaic stations. It ensures a reliable power supply and energy security in distributed and off-grid applications.

Multi-Scenario Adaptability

·Multifunctional integration with support for PV and generator access

·Seamless on-grid to off-grid switching in less than 20ms

Economical & Efficient

·High energy efficiency for optimized performance

·Factory pre-assembled, fast deployment, and easy transportation

·Advanced thermal management improves battery lifespan and system discharge capacity

Real-time monitoring and Control

·24/7 real-time monitoring and control, both remote and on-site

·Intelligent early warning system, automated safety checks, and elimination of potential hazards

Flexible & expandable

·Single unit capacity of 1,290 kWh

·Supports up to 8 units in parallel for large-scale energy expansion

Model	Magic-ZCube1290-MF
AC Parameter
Rated Power (kVA)	500
Rated Voltage (V)	400
Voltage Range (V)	320-460
Rated Current(A)	722
Rated Frequency (Hz)	50/60
Isolation Method	Transformer
Over Power	110%long time;120% 1min
PV Parameter
Rated MPPT Quantity	10
Rated MPPT Module Power (kW)	50
Max output Power (kW)	600
MPPT Voltage Range	250-850
MPPT voltage range @full load (V)	450-850
Battery Parameter
Cell Type (Ah)	LFP280
Battery Module Rated Voltage (V)	51.2
Battery Module Energy (kWh)	14.336
Rated Voltage ()	768
Voltage Range (V)	672-850
Battery Energy (kWh)	1290
General Parameter
Max. System Efficiency	≥90%
IP Rating	IP54
Anticorrosion Grade	StandardC4
Cooling Method	HVAC
Operating Temperature Range	-20-50C
Operating Humidity	0%-95%R.H
Max. Charging/Discharging Rate	<2000
Elevation (m)	Integrated
Dimension:WDH (mm)	605825912438
Total Weight (t)	20
Communication Port	CAN, RS485,ETH
